Coffee Roaster Troubleshooting: Burner, Drum, Probes and Airflow — What to Check Before You Call

Two rules before any symptom

Airflow first. More of the ignition and flame problems you will meet trace back to a blocked air path than to the burner itself. Chaff in your cyclone, a full collector, a fouled fan impeller or a chimney narrowed by deposits starves the burner of air or trips the pressure switch that protects it. Before you touch an igniter, check that your fan runs, the damper moves, the collector is empty and the flue draws. You will fix a good share of this list right there.

Never bypass a safety device. The high-limit thermostat, the flame-failure sensor and the emergency stop are what stand between a fault in your machine and a fire in your building. Any diagnosis that involves jumping one of them out is a test for a technician, done cold — never a way for you to get through the morning's orders.

Symptom 1 — the machine will not power up

Your five-minute check: main isolator on; the machine's own switch in the run position; fuses on the panel (keep spares on your shelf — see spare parts to keep); the emergency stop released; on machines with a control cabinet, the cabinet's breaker. If you have a PLC or touch-screen machine and the screen is blank while the cabinet is live, look at the screen's supply, not the roaster.

Stop and call if a fuse blows again on replacement, you smell hot insulation, or your residual-current device trips as soon as the heating elements come on — that last one is usually an element that took in moisture during a wash-down or a long shutdown, and it is not something you reset your way out of.

Symptom 2 — the burner will not attempt to light

Your gas machine runs an ignition sequence: fan proven, air-pressure switch closed, gas valve opened, spark, flame proven. When nothing happens at all, work down that sequence in order — it is the fastest way to tell your technician where it stopped.

1. Fan. Is your combustion or exhaust fan actually running? If it is not, no pressure switch closes and no gas is released — check this before anything else.
2. Air pressure switch. Blocked ducting holds it open, so you are back at the airflow rule above.
3. Gas. Supply valve open, LPG bottle not empty or frozen, inlet pressure at what your machine needs — our natural-gas machines want at least 3 kPa, and the SD-3 Pro specifies 6 kPa on LNG and 5 kPa on LPG. If you have never measured what your regulator delivers under load, do it now: a starved burner looks exactly like a faulty one. Gas-pressure switches on larger burners must see pressure inside their band.
4. Spark. With the panel open and the machine calling for ignition, you should see or hear a spark at the electrode. If you get none, the fault is in the ignition lead, the electrode gap (a few millimetres from the burner surface on most designs) or the controller — note which, then hand it to your electrician.

Stop and call if you smell gas at any point, if the controller goes to lockout repeatedly, or if anyone on your team has lit the burner with a match "to get through the morning."

Symptom 3 — the burner lights, then drops out

The flame proves for a moment and the controller shuts the valve. You are looking at three causes, in the order you should check them:

• Flame sensor. The flame rod or UV sensor has to see the flame; a rod coated in deposits, bent away from it, or with a damaged lead reports no flame and the valve shuts. Clean the rod with fine abrasive, check its position, check the lead — this one you can usually do yourself in ten minutes.
• Marginal air or gas pressure. Enough to start, not enough to hold: your bottle running low, an undersized regulator, a long horizontal flue. The pressure sags as the burner draws and the switch opens, which is why it often happens on your third or fourth batch rather than your first.
• High-limit thermostat. If the machine relights after a manual reset and then trips again, the over-temperature cut-out is doing its job — either your roaster genuinely overheated (airflow again, or a runaway profile) or the sensor feeding it has failed. A technician tests this by isolating the sensor cold. Your job is to write down when it tripped and at what reading, then stop for the day.

Symptom 4 — the drum does not turn, or turns roughly

Your five-minute check, cold: disconnect the drive (chain or belt) and turn the drum by hand. Free and silent means your drum and bearings are fine — look at the motor, its capacitor or contactor, the belt tension or a sheared drive key. Stiff, gritty or scraping at one point in the turn means the bearings, or a drum that has settled onto the front plate; the sequence for that is in coffee roaster drum bearings.

A drum that hesitates when hot but turns freely cold is usually a belt slipping as it warms or a bearing tightening with heat — note which, because it changes what you order. On our YS series the drum has its own motor, separate from the cooling and exhaust fans. A drum fault does not strand a batch on your cooling tray, and a fan fault does not stop your drum.

Stop and call if the motor hums without turning (seized bearing or failed capacitor — switch it off, do not leave it trying) or if you hear a loud crack from the drive.

Symptom 5 — the probe reads wrong, or jumps

If your bean probe reads low and lags, it is usually coated with oil and chaff; if it jumps around, you are usually looking at a wiring fault — a lead trapped under a panel, an oxidised connector, or the thermocouple type set wrongly in the software so your error grows as the roast gets hotter. The three-step check, from wiring to cleaning to replacement, is in coffee roaster temperature probe calibration. A probe fault is never a reason to roast by colour on a production machine — every batch you make that way is one you cannot repeat.

Symptom 6 — smoke in the room, weak exhaust

Airflow again. Your cyclone and collector full, the fan impeller caked, a damper linkage slipped, the flue cap blocked by debris or a bird, or a duct crushed. Airflow falls with the square of any narrowing, so your duct has lost most of its capacity long before it looks blocked — which is why this arrives as a slow drift rather than a failure. If your machine smokes into the room with the fan running, treat it as a cleaning job first and a fan job second; put the intervals in your calendar from the maintenance schedule.

Stop immediately if exhaust temperature climbs while your burner is steady, or if you see a glow or smell burning chaff at the collector — that is a duct fire starting. Close the damper, shut the gas, and follow the procedure in coffee roaster fire safety. Rehearse it with your staff before you need it.

Symptom 7 — cooling takes longer than it did

Perforations in your cooling tray blocked with oily fines, the fan intake clogged, or the stirring arms not turning. Clean the tray and the fan; if your tray shares a motor with the drum, a slipping belt shows up here first. Watch this one, because slower cooling adds development to every batch you drop — your customers taste it before your machine shows it, and it quietly costs you batches per hour as well.

The chart

Print that table and tape it inside your control cabinet door. The middle column is what you do before you phone anyone; the right column is where you stop and let a technician take over.

What "call" means on an imported roaster

You are not waiting for a technician to fly in. The model that works has three parts: remote diagnosis first — a video call with the fault on screen, your panel open and a multimeter in your hand resolves most of the table above to a named part; parts by air — in the first year, parts that fail without human damage are replaced and sent to you by air express at our cost, and every machine ships with 24/7 lifetime phone and online technical support; local hands — your own electrician or gas fitter fits the part after the call. Line up that local contact before you need them, and keep three things where you can grab them: your serial number, a photo of the nameplate, and the batch log for the day it failed. That is why the coffee roasting batch record matters to your mechanic as much as to you.

FAQ

How do I tell my supplier what is wrong so the first reply is useful?

Send four things in one message: what the machine did and at which minute of the roast, what the screen or gauges read at that moment, a photo of the nameplate with the serial number, and the batch log for that day. That turns a two-day exchange of questions into one video call. Vague reports ("it won't light") cost you a roasting day in time-zone ping-pong.

Which faults am I allowed to fix myself, and which need a licensed trade?

Cleaning, fuses, belts, probe wiping and anything you can reach with the gas off are yours. Anything inside the gas train, the flue, or the electrical cabinet beyond a fuse belongs to a licensed gas fitter or electrician in your country — not because the work is hard, but because your insurer and your inspector will ask who did it. Keep the invoice.

What should I have on the shelf so a fault does not stop the week?

A fuse set, a spare bean thermocouple, a drive belt, a door seal and a chaff screen. Together they cover the failures that are common and cheap, and they turn a three-week courier wait into a twenty-minute job for you. Order them with the machine — shipping five small parts with a crate costs you nothing extra, and buying them one at a time later costs you a week each time.

What does the high-limit switch on a coffee roaster do?

It cuts the burner when a temperature sensor reads above a safe ceiling, protecting your machine and your room from a runaway roast or a blocked exhaust. If it trips, find out why — airflow or profile — rather than resetting it again, and never run with it disabled. An inspector who finds a bypassed high limit can shut you down on the spot.

How do I stop the same fault coming back next month?

Write down every stoppage with its date, the reading at the time and what fixed it. Three entries is usually enough to show a pattern — a bearing that gets noisy every eight weeks is telling you something a single incident cannot. Pair that log with a fixed cleaning calendar and most of the symptoms above stop appearing at all.

How long can I keep roasting with a fault I know about?

If it touches gas, flame proving, the high limit or the exhaust, not one more batch. If it is cosmetic or a slow drift — a sticky door seal, a probe reading a little low — you can finish the day, but book it in the same week. Faults on roasters almost never stay the same size, and the cheap window for fixing them is short.

Final Thoughts

Check airflow before the burner, hand-turn the drum before you blame the motor, fix the probe before you roast by eye, and never bypass a safety device. We build the SD series and YS series with independent motors and PLC or Siemens control that put the fault on the screen, and we back every machine with remote diagnosis and air-freighted parts.
